Description

CMI manufactures single cartridge filters vessels in SS304 or SS316L for up to 30inch length with a single or double open-end cartridge.

Our single cartridge filter vessel allows users to enjoy a simple and easy to use design for economical usage.

They can be applied in many industrial applications with liquid of low to medium viscosity.
The structure is stable and can be calculated and constructed acc. to ASME Section VIII, Division 1.

Features

－Simple and easy handling
－Economic design
－Length can be up to 30inch
－Fix perfectly with all standard filter cartridges
－Can be assembled with all standard filter cartridges
－Easy cleaning of inner & outer surface

Data & Specifications:

－Length: 10inch to 30inch
－Connection: BSP, NPT
－Design Pressure: 6bar
－Design Temp: 120 deg C
－Material: SS304 & SS316L
－Gasket: Buna, EPDM, Viton, PTFE
－Surface Treatment: E-polishing
